Guide to Comparing Particular Properties
Definitions of Terms
Product Specifications:
| Performance Data IRis 70 | |
| Visible Light Transmission | 67% |
| Visible Light Reflectance | 9% |
| Total Solar Energy Rejection | 54% |
| Shading Coefficient | .53 |
| Total Solar Absorption | 54% |
| Luminous Efficacy | 1.26 |
| Ultraviolet (UV) Rejection | 99% |
Film on 6mm glass.
| Performance Data - Geo 30 | |
| Visible Light Transmission | 32% |
| Visible Light Reflectance | 13% |
| Total Solar Energy Rejection | 60% |
| Shading Coefficient | .46 |
| Total Solar Transmission | 25% |
| Total Solar Absorption | 55% |
| Glare Reduction | 64% |
| UV Rejection | 99.9% |
Film on 3mm glass.
| Performance Data - Geo 40 | |
| Visible Light Transmission | 43% |
| Visible Light Reflectance | 11% |
| Total Solar Energy Rejection | 53% |
| Shading Coefficient | .56 |
| Total Solar Transmission | 33% |
| Total Solar Absorption | 50% |
| Glare Reduction | 51% |
| UV Rejection | 99.9% |
Film on 3mm glass.
| Performance Data - Geo 50 | |
| Visible Light Transmission | 51% |
| Visible Light Reflectance | 10% |
| Total Solar Energy Rejection | 47% |
| Shading Coefficient | .63 |
| Total Solar Transmission | 42% |
| Total Solar Absorption | 43% |
| Glare Reduction | 42% |
| UV Rejection | 99.9% |
Film on 3mm glass.
Guide to Comparing Particular Properties
| Measures of Effectiveness For Preventing Fading: | |
| Ultraviolet (UV) Rejection | Higher is better |
| Total Solar Energy Rejected | Higher is better |
| Measures of Effectiveness For Day Lighting: | |
| Visible Light Transmission | Higher is better |
| Measures of Effectiveness For Energy Savings: | |
| Total Solar Energy Rejected | Higher is better |
| Shading Coefficient | Lower is better |
| Measures of Effectiveness For Reducing Heat Gain: | |
| Total Solar Energy Rejected | Higher is better |
| Shading Coefficient | Lower is better |
| Measures of Effectiveness For Preventing Glare: | |
| Visible Light Transmission | Lower is better |
Back to Top
Definitions
Visible Light Transmission
An indicator of how much visible light passes through the glass and into the room.
Ultraviolet (UV) Rejection
An indicator of the amount of ultraviolet (UV) energy that is blocked from passing through the glass.
Total Solar Energy Rejected
An indicator of the films ability to reject solar energy.
Infra-red Rejected
An indicator of infrared blocked at a specific wavelength.
Visible Light Reflectance
An indicator of the amount of visible light that is reflected away from the glass.
Total Solar Absorption
An indicator of how much energy is being absorbed by the glass.
Shading Coefficient
An indicator of the effectiveness of window film in rejecting heat as compared to clear glass.
